Size Guide
| Measurement |
One Size |
| Recommended Rider Height |
4’10” ~ 6’5” |
| Reach |
350 mm |
| Handlebar Height |
1180 – 1150 mm |
| Wheelbase |
1090 mm |
| Stand-Over Height |
370 mm |
| Min Saddle Height |
590 mm |
| Max Saddle Height |
983 mm |
| Rear Track Width |
725 mm |
| Total Length |
1647 mm |
Specifications
Size Guide
| Bike Size |
One Size |
| User Height Range |
4’10”-6’5” |
Frameset
| Frame |
Aluminum Alloy |
| Fork |
Hydraulic suspension 80mm travel with Lock-out |
Electronics
| Motor Hub |
48V, 750W, 1300W Peak, 90Nm |
| Battery |
48V, 16.75 Ah, IPX7, Certificated by UL 2271 |
| Cell |
18650 cell, Certificated by UL 2580 |
| Charger |
48V, 3.0A Fast Charger |
| Display |
3.5″ Full color, High brightness, Bluetooth, Adjustable angle |
| Sensor |
Torque and Cadence Sensor |
| USB Port |
USB Type-C phone charge |
| Throttle Assist |
Trigger-control, removable |
| Pedal Assist |
5 PAS Levels |
| Walk Mode |
2.0 MPH |
| Front Light |
Light sensing 130 Lux / 500 LM high-output integrated LED, adjustable angle |
Lighting & Features
Integrated lighting and smart features
| Rear Light |
Braking Indicator, turn signal, rear light steady/flash, integrated with rear rack |
| App & Apple Find My™ |
APP OTA & Find My |
| Turn Light |
Left/Right turn signal with click indicator |
| Horn |
Electric horn integrated with front light, 90 db |
Speed & Range
| Max Speed (Default) |
12 MPH |
| Max Speed Adjustable Range |
8~20 MPH |
| Class |
1 / 2 |
| Throttle Range |
50 Miles |
| Pedal Assist Range |
60 Miles |
| *Range Note |
Max range determined using PAS 1 on flat terrain with a rider weight of 198 lb. |
Drivetrain
| Chainrings |
40T, narrow wide chainring |
| Crankset |
Aluminum Alloy, 152mm |
| Freewheel |
7-speed, 11-28T |
Transmission
| Chain |
KMC 7-speed |
| Rear Derailleur |
SHIMANO 7-speed |
| Shift Lever |
SHIMANO 7-speed |
Brake
| Brake |
Hydraulic Disc Brake |
| Rotors |
180mm Front and Rear |
| Brake Levers |
Aluminum Alloy with power cutoff and parking brake |
| System |
Hydraulic braking system |
| Safety |
Motor power cut-off when braking |
| Parking |
Integrated parking brake |
Wheel
| Rims |
Double-wall Aluminum Alloy |
| Front Hub |
Aluminum alloy, nutted |
Tires
| Tire |
KENDA 20×3.0″ eBike puncture-resistant tires |
| Type |
Puncture-resistant eBike tires |
Cockpit
| Handlebar |
Aluminum Alloy, Φ31.8mm, 660mm |
| Grips |
Durable ergonomic grips, lockable |
Seat System
| Saddle |
VELOTRIC Triker seat with adjustable back rest |
| Seatpost |
Aluminum Alloy φ30.9mm 350mm / Aluminum Alloy φ34.9mm 260mm |
Supports
| Fenders |
Front and rear full coverage |
| Rear Rack |
Aluminum Alloy |
Pedals
| Pedals |
Plastic |
| Type |
Platform style |
Weight & Load
| Bike Weight |
85.8 lbs |
| Max Bike Load |
500 lbs (including rear basket load) |
Certification
| UL Certification |
UL 2849 |
| ISO Standard |
ISO 4210 |
