Size Guide
| Measurement |
Regular |
Large |
| Recommended Rider Height |
5’2″ ~ 5’10” |
5’7″ ~ 6’5″ |
| Reach |
446 mm |
459 mm |
| Handlebar Height |
1000 mm |
1050 mm |
| Wheelbase |
1210 mm |
1224 mm |
| Stand-Over Height |
720 mm |
720 mm |
| Min Saddle Height |
790 mm |
830 mm |
| Max Saddle Height |
1000 mm |
1050 mm |
| Total Length |
1930 mm |
1943 mm |
Specifications
Size Guide
| Bike Size |
Regular / Large |
| User Height Range |
R: 5’2”~5’10”
L: 5’7”~6’5” |
Frameset
| Frame |
Triple-Butted Aluminum Alloy |
| Fork |
RST Air Suspension 120mm Travel with Lock-out, Rebound Adjustable |
Electronics
| Motor |
48V, 750W (1300W Peak Power), 100Nm |
| Battery |
48V, 16.7Ah (801.6Wh), IPX7, Certificated by UL2271 |
| Cell |
Samsung/LG 21700 cell, Certificated by UL2580 |
| Charger |
48V, 3A Fast Charger |
| Sensor |
Torque and Cadence Sensor |
| Display |
2.0″ Left-mounted Full-color Display with High Brightness, Bluetooth, NFC |
| USB Port |
USB Type-C phone Charge |
| Throttle |
Trigger-control, Removable |
| Pedal Assist |
4 Riding Modes + Pulse Mode / Ride Tuning |
| Walk Mode |
2.9 MPH / Walk & Hold |
| Front Light |
500LM High-output Integrated LED, Adjustable Angle |
Lighting & Security
Integrated lighting and smart anti-theft features
| Rear Light |
Brake highlight, Turn Signal |
| Water Resistant |
IPX6 |
| Anti-theft |
Apple Find My & Android Find Hub, NFC Card Unlock |
| Connectivity |
Bluetooth & NFC |
Speed & Range
| Max Speed (Default) |
20 MPH |
| Max Speed Adjustable Range |
12~28 MPH |
| Ebike Class |
Class 1 / 2 / 3 |
| Pedal Assist Range |
95 Miles |
| Throttle Range |
70 Miles |
| Range Note |
Range may vary depending on rider weight, terrain, and assist level. |
Drivetrain
| Chainrings |
BCD 104, 40T Narrow-Wide Chainring |
| Crankset |
Aluminum Alloy, 165mm |
| Cassette |
9-speed, 11-46T |
Transmission
| Rear Derailleur |
SHIMANO Cues, 9-speed |
| Shift Lever |
SHIMANO Cues, 9-speed |
| Chain |
KMC XGlide 9-speed |
Brake
| Brake |
SHIMANO MT200 Hydraulic Disc Brake |
| Rotors |
180mm Front and Rear |
| Brake Levers |
Aluminum Alloy with Power Cutoff |
| System |
Hydraulic braking system |
| Safety |
Motor power cut-off when braking |
| Performance |
High-performance Shimano braking system |
Wheel
| Rims |
Double-wall Aluminum Alloy |
| Front Hub |
NOVATEC Aluminum Alloy, 15x110mm Thru-axle |
Tires
| Tire |
Kenda 27.5×2.4″ MTB Puncture Resistant Tires |
| Type |
MTB puncture-resistant tires |
Cockpit
| Handlebar |
Aluminum Alloy, Φ31.8mm, 740mm |
| Grips |
Durable Ergonomic Grips, Lockable |
Seat System
| Saddle |
VELOTRIC Comfort Ergonomic Seat |
| Seatpost |
Aluminum Alloy, φ31.6mm, 350mm |
Supports
| Fenders |
Plastic, Front and Rear Full Coverage |
| Rear Rack |
Optional |
Pedals
| Pedals |
Plastic |
| Kickstand |
Aluminum Alloy, Included, Rear Mount |
Weight & Load
| Bike Weight |
57 lbs |
| Rear Rack Load Capacity |
66 lbs |
Max Load
| Max Bike Load Capacity |
440 lbs |
| Weight Note |
*Weight does not include fenders, kickstands, or pedals. |
Certification
| UL Certification |
UL2849 & UL2271 |
| ISO Standard |
ISO 4210 |
